| Specifications | Camera Perfomance |
| Sensor | Gpixel Gsense 400 BSI CMOS Gen IV, Grade 1 in
imaging area |
| Active Array Size | 1608 x 1608 pixels ( 2.58 Megapixel ) |
| Pixel Area | 11µm
x 11µm ( 121µm² ) |
| Sensor
Area | 17.69 mm x 17.69 mm |
| 25mm diagonal |
| Peak QE% | >95% |
| Read Noise | 1.6e- ( Medium ) |
| 1.8e- ( RMS ) |
| Full - Well capacity | 80,000e- ( Combined Gain ) |
| Dynamic Range | 50,000 : 1 ( Combined Gain ) |
| Bit Depth | 16 - Bit ( Combined Gain ) |
| Readout
Mode | Rolling Shutter |
| Effective Gloval
Shutter |
| Binning | 2 x 2 ( on FPGA ) |
| | | | | | | | | | | | |
| | | | | | | | | | | | |
| Cooling Perfomance | Sensor Temperature | Dark Current |
| Air Cooled | -10°C @ 30°C Ambient | 2.9e- / pixel / second |
| Liquid Cooled | -25°C @ 30°C Ambient | 0.7e- / pixel / second |
| | | | | | | | | | | | |
| | | | | | | | | | | | |
| Specifications | Camera Interface |
| Digital Interface | PCLe , USB3.0 |
| Lens Interface | F - Mount |
| Mounting Points | 2 x ¼ 20" mounting points
per side to prevent rotation |
| Liquid Cooling | Quick Disconnected Ports |
| | | | | | | | | | | | |
| | | | | | | | | | | | |
| Triggering Mode | Function |
| Input
Trigger Modes | Trigger - Firdt - Sequence triggeried on first
rising edge |
| Edge - Each frame
triggered on rising edge |
| SMART
Streaming : Fast interation through multiple exposure times | | | |
| Output
Trigger Modes | First Row : Exposure signal is high while first row
is acquiring data |
| Arry Rows : Expose
signal is high while arry row is acquring data |
| All Rows : Effective
Global Shutter - Exposure signal is high when all rows are acquiring data |
| Output Trigger
Signal | Exposure Out ( up to four signals ), Read Out,
Trigger Ready |
| | | | | | | | | | | | |
