| Specifications |
| Sensor Type | Sony ICX - 674 Monochrome Scientific Interline CCD |
| CCD Array | 1920 x 1460 |
| Pixel Size | 4.54µm x 4.54µm |
| Sensor Dimension | 8.8mm x 6.6mm ( 11mm diagonal ) |
| Peak Quantum
Efficiency | 75% at 600nm |
| Full Well Capacity | > 16,000e- signal pixel ( > 22,000e- with on -
chip binning ) |
| Digital Output | 14 bit |
| Digitzation Rate | USB 3 : 50 MHz high frame rate |
| Read Noise | 5.2 e- RMS |
| Frame Rate | 14.4fps ( full resolution ) and 24.1 fps ( binned 2
x 2 ) |
| Exposure Time Range | 25µs - 60min |
| Supported Binning
Modes | 1 x 1, 2 x 2, 4 x 4, 6 x 6, 8 x 8, 12 x 12, 16 x 16,
24 x 24 |
| Dark Current Rate (
typical ) | 0.0006 e/p/s at -12°C regulated |
| Cooling | -12°C |
| Intellingent
Quantification Feature | Defect correnction ( nearest neighbor ) |
| Computer Platforms /
Operating Systems | Window 7, 8.1 , and 10 ( 64 -bit / 32 - bit ) |
| Digital Interface | USB 3.0 ( USB 2.0 compatible at reduced max fps ) |
| Triggering I/O
Signals | Trigger in, Exposure Out, End - of - Frame, Shutter
Out |
| Supported Triggering
Modes | Trigger first, Storbe , Bulb |
| Optical Interface | 1" , C - mount optical format |
| Mounting Hole Thread
Size | 1/4" - 20 thread, 4 sides |
| Camera Dimensions | 98.4mm x 76mm x 76mm ( length x width x height ) |
| Weight | 1.55lb,
0.72kg |
| Power Requirement | 7.5 V DC, 2.5A |
