| DVA Specifications |
| Wavelength
sensitivity | 400 to 750nm |
| Transpermission per Image | >88 ( dose not include filter ) |
| Operation
Temperature | 10 to 37°C |
| Detector attachement | C - mount ( male ) |
| Front attachement | C - mount ( female ) |
| External mounting
option | ¼ - 20 tapped hole on back of unit |
| Dimension | 320mm long , 110mm wide , 79mm tall |
| Weight | 1.5kg |
| Filters | Emission / barrier
: 25mm diameter |
| Dichroic : 25 - 26 mm wide, 36 - 40 mm long, 1 - 3
mm deep |
| | Recommend Chroma Ultra Flat range in size 26 x 38 x
2 mm for best result |
| Supports LightsSpeed
mode of Evolve 512 Delta with firmware newer than 12. 2014 | |
