| CCD Sensor |
| Sensor Type | Sony ICX - 825 Scientific Interline CCD ( Monochrome
) |
| CCD Array | 1360 x 1024 |
| Pixel Size | 6.45 µm x 6.45 µm |
| Sensor Dimensions | 8.8 mm x 6.6 mm ( 11mm diagonal ) |
| Peak Quantum
Efficiency | 75% at 600 nm |
| Full Well Capicity | > 11,000 e- single pixel |
| Camera | |
| Digital Output | 14 bit with 50MHz readout |
| Digitization Rate | USB 3 : 50MHz high frame rate |
| Read Noise ( typical
) | < 5.5e - RMS with 50MHz readout |
| Frame Rate | 22 fps ( full resolution ) |
| Exposure Time Range | 25µs - 5sec |
| Supported Binning
Modes | 1 x 1, 2 x 2, 4 x 4, 6 x 6, 8 x 8, 12 x 12, 16 x 16 |
| Dark Current Rate (
typical ) | 0.036 e/p/s at -15︒C regulated |
| Sensor Cooling | 0︒C stabilized at 22︒C ambient, Thermoeletric
cooling with converction |
| Intelligent
Quantification Feature | DPC - Delective Pixel ) Correction |
| Interfacing | |
| Computer Platforms /
Operating Systems | Window 7 ( 64bit ), Window 8 ( 64bit ), Window 10 (
64bit ) |
| Refer to the Qimaging website for the latest list of
minimum computer recommendations |
| Digital Interface | USB3.0 |
| Tfiggering I / O
Single | Trigger In , Exposure Out, End - of - Frmae, Shutter
Out |
| Trigger First, Storbe, Bulb |
| Mechanical | |
| Optical Interface | 1" C - mount optical format |
| Mounting Hole Thread
Size | 1/4" - 20 thread 4 head |
| Camera Dimensions | 98.4mm x 76mm x 76mm ( lengh x width x height ) |
| Weight | 1.55lb , 0.72kg |
| Power Requirement | 7.5 V DC, 2.5A |
