| CCD Sensor |
| Sensor Type | Sony ICX - 695 Scientific Interline CCD ( Color ) |
| CCD Array | 2688 x 2200 |
| Pixel Size | 4.54 µm x 4.54µm |
| Sensor Dimensions | 12.5mm x 10mm ( 16mm diagonal ) |
| Camera | |
| Digital Output | 14 bit |
| Read Noise ( typical
) | < 6e - RMS |
| Frame Rate | 7.1 fps 6 Milion Pixels Color |
| 7.1 fps 6 Milion Pixels Monochrome |
| 12.81 fps ( Bin 2 ) 1.5 Milion Pixels Monochrome |
| Dark Current Rate (
typical ) | 0.0007 e/p/s at -12︒C regulated |
| Sensor Cooling | -12︒C stabilized at 22︒C
ambient, Thermoeletric cooling with forced air |
| Interfacing | |
| Computer Platforms /
Operating Systems | Window 7 ( 64bit ), Window 8 ( 64bit ), Window 10 (
64bit ) |
| Refer to the Qimaging website for the latest list of
minimum computer recommendations |
| Digital Interface | USB3.0 ( USB2 compatible at reduced max fps ) |
| Mechanical | |
| Optical Interface | 1" C - mount optical format |
| Mounting Hole Thread
Size | 1/4" - 20 thread 4 head |
| Camera Dimensions | 98.4mm x 76mm x 76mm ( lengh x width x height ) |
| Weight | 1.55lb , 0.72kg |
| Power Requirement | 7.5 V DC, 2.5A |
